Description
- Inner & Outer Chambers & Lid Made of Stainless Steel 304
- Radial Locking System with Paddle Lift
- Water Level Indication Glass Window
- Simple Operation
Safety Features
- Pressure Gauge
- Safety Valve
- Pressure Control Switch
- Digital Temp. Controller and Timer
- Audio Alarm System
Options
- Double Wall Single Chamber
- Triple Wall Double Chamber
- Steam Jacket and Storage System
- Moisture Trap System
- Low water cut-off
| MODEL | HPV1222 | HPV1624 | HPV1830 |
| SIZES | 12″X22″ | 16″ X 24″ | 18″ X 30″ |
| CAPACITY | 40 LTRS | 70 LTRS | 125 LTRS |
| WORKING PRESSURE | 10-20 PSI | ||
| WORKING TEMP | 121 DEGREE C | ||
| POWER | AC 220V. 50HZ / 6KW / 9 KW | ||
| BODY | Stainless Steel 304 | ||
*Please ask for customized solutions also.
Capacity & Dimensions
